1
Voltage Gate
PASSDevice output type must match generator output.
120V required -> 120V available
Yes, the Pecron E3600LFP can run a Portable Oxygen Concentrator
This pairing clears the safety headroom. Required ~403W running and 403W surge; the Pecron E3600LFP is rated 3600W / 7000W.
Power Margin Analysis
3600W / 7000W Capacity Running 3197W headroom
403W required
Surge 6597W headroom
403W required
Decision Gate Waterfall
Same decision gates as the engine: voltage, running, surge. Runtime is shown as operational context.
2
Running Gate
PASSContinuous draw with safety buffer applied.
403W required -> 3,600W available (3,197W headroom)
Required 403W required
Available 3,600W
3
Surge Gate
PASSStartup peak with safety buffer applied.
403W required -> 7,000W available (6,597W headroom)
Required 403W required
Available 7,000W
4
Runtime Insight
INFORuntime context only. It does not change the electrical compatibility verdict.
Continuous estimate: 6.1h
Device profile reference: up to 24h per day.
Power bars show required versus available output for each gate.
View full compatibility reportDecision Snapshot
Quick compatibility, required headroom, and model-specific context at a glance.
⚡
3600W
Running Power
🔋
3072Wh
Capacity
⏱️
~6.1h
Est. Runtime
☀️
2400W
Solar Input
Quick Compatibility Check
- 1 Running headroom: target 403W; generator provides 3600W.
- 2 Surge headroom: target 403W; generator provides 7000W.
- 3 Tip: leave headroom for startup spikes and warm conditions.
Model-Specific Results
3 of 3 models are SAFE or TIGHT. Most demanding model: Philips EverFlo (350W surge).
| Model | Running | Surge | Verdict | Runtime | Source |
|---|---|---|---|---|---|
| Philips SimplyGo | 150W | 150W | Safe | ~14.3h | Engineering Est. |
Show expert analysisTechnical: **Running load:** 150 W. **Surge:** 150 W. **Voltage:** 120 V AC. No inrush spike, consistent draw across flow settings. Field note: Verify power station inverter can deliver 150 W continuously for 24-hour cycles. Monitor battery state of charge during overnight operation. Can I run this concentrator on battery backup during a power outage? Only if your power source can supply at least 150W continuous and 150W surge at 120V. | |||||
| Philips EverFlo | 350W | 350W | Safe | ~6.1h | OEM Verified |
Show expert analysisTechnical: **Running load:** 350W continuous. **Surge:** 350W (no inrush spike). **Voltage requirement:** 120V AC. Resistive heating element drives steady draw with minimal transient. Field note: Ensure power station inverter handles 350W continuous without thermal cutoff. Voltage deviation beyond ±5% may trigger device fault alarms. Can I run this on a portable power station during an outage? Only if your power source can supply at least 350W continuous and 350W surge at 120V. Verify capacity in watt-hours exceeds your runtime need. | |||||
| Drive DeVilbiss 5L | 310W | 310W | Safe | ~6.9h | Engineering Est. |
Show expert analysisTechnical: **Running load:** 310W continuous. **Surge:** 310W (no starting transient). **Voltage:** requires 120V AC. The device demands 7440 Wh over a 24-hour period. Field note: Medical oxygen concentrators tolerate no interruption. Verify the power station supports pass-through charging during mains operation. Can I run this oxygen concentrator on a portable power station during an outage? Only if your power source can supply at least 310W continuous and 310W surge at 120V. No compatibility is guaranteed. | |||||
How This Pairing Performs Across Our Database
This unit ranks #23 of 29 compatible generators for this device by buffered margin (Overkill class).
How Portable Oxygen Concentrator Performs Across 33 Tested Generators
29 of 33 generators are SAFE+TIGHT for Portable Oxygen Concentrator.
29
Safe+Tight
Safe 29 (88%)
Fail 4 (12%)
Power Comparison: Pecron E3600LFP vs Top Alternatives for Portable Oxygen Concentrator
Pecron E3600LFP Safe Overkill
Current unit
Running 3,600W
Surge 7,000W
Fit class uses buffered needs (running and surge) for this device.
Specs & Surge Analysis
Medical
Portable Oxygen Concentrator
Medical Emergency Backup
Select Your Model:
350W
Running
350W
Surge
120V
Required
True Surge™ Analysis
Safety Buffer: +15% Running Power Usage 11% Utilization
403W required 3600W Capacity
3197W headroom
Surge/Startup Peak 6% Utilization
403W required 7000W Capacity
6597W headroom
Voltage Match 120V ↔ 120V ✓
Compare Similar Units
Free Tools
Station Tools
Generator Insights
The 7000W surge rating handles demanding startup loads including well pumps, air compressors, and window AC units. The dual 1200W MPPT controllers accept high-voltage panel strings (up to 150V), enabling efficient solar recharging in 1.5–2 hours with 2400W of panels. At 3072Wh base capacity, expect 8+ hours of runtime on moderate loads. The expansion to 15kWh rivals whole-home battery systems.
The E3600LFP uses LiFePO4 chemistry rated for 3,500+ cycles to 80% capacity. The 51.2V battery architecture and UPS function (8–20ms switchover) make it suitable for sensitive electronics and home backup. The TT30-R RV outlet follows NEMA standards for safe 30A connections. Source: Pecron official US product page (manufacturer documentation).
Extend Runtime with Solar
Keep your Portable Oxygen Concentrator running with solar • MPPT: 32– 150V • Max: 2400W
Smart Value Anker
400W Panel
1 Hour Sun =
+0.8h per sun hour
MC4 -> XT60
Full in ~11h Adapter required: MC4 -> XT60.
Smart Value EcoFlow
400W Panel
1 Hour Sun =
+0.8h per sun hour
MC4 -> XT60
Full in ~11h Adapter required: MC4 -> XT60.
Technical Analysis
Spec-Based • No GuaranteesTechnical Breakdown
Running range: 150W (portable SimplyGo) to 350W (stationary EverFlo). Surge: modeled equal to running — no OEM startup current published for any oxygen concentrator in this class. Voltage: 120V AC.
Expected Behavior
Estimated runtime: ~6.1h. Stationary concentrators operate 24 hours daily at constant draw, consuming 7,440-8,400 Wh per day. Portable units draw less but still require continuous power for uninterrupted oxygen delivery.
Field Note
Oxygen concentrators are life-critical — always have a backup power source. Use pure sine wave output only. Verify pass-through charging capability so the power station stays charged while the concentrator runs on mains power.
Frequently Asked Questions
Can the Pecron E3600LFP power a Portable Oxygen Concentrator?
Yes. The Pecron E3600LFP provides 3600W running / 7000W surge. The Portable Oxygen Concentrator needs 403W / 403W (including 15% buffer). That leaves 3197W of running headroom and 6597W of surge margin.
How long will the Pecron E3600LFP run a Portable Oxygen Concentrator?
Approximately 6.1 hours, based on the Portable Oxygen Concentrator's 350W draw and the Pecron E3600LFP's 3072Wh capacity (70% usable after real-world losses).
What Else Can You Run?
With 1230W allocated to the Portable Oxygen Concentrator, the Pecron E3600LFP still has ~1300W of margin. These devices could run simultaneously:
❄️
Medical Fridge
80W
🩺
CPAP (No Humidifier)
40W
🌬️
Nebulizer
60W
📱
Smartphone Fast-Charge
20W
🥪
Microwave (Running)
1000W
🖥️
24' Monitor
30W
Pro Tip for Medical Users: According to energy reports, turning off the humidifier on your Portable Oxygen Concentrator can double your runtime. Using a DC cable instead of the AC plug is also recommended to avoid inverter inefficiency.
Compare all 33 generators for the Portable Oxygen Concentrator
Ranked by budget, runtime, and overall compatibility.
Related Guides: How to Size a Power Station
Technical Sourcing & Verification
ID: pecron-e3600lfp-oxygen-concentrator 🏛️ Device Data Source
Engineering Est. Safety Factor Applied
Derived from variant list (max of variants). Running worst case = Philips EverFlo (350W). Surge = running for all variants (no OEM startup current published for any oxygen concentrator in this class; surge modeled equal to running).
⚡ Generator Specs Source
OEM Verified
Pecron E3600LFP Official Product Page (US) — full specifications
Methodology informed by US Department of Energy (DOE) & EIA references where applicable.
